ETher NDE SigmaCheck 2 Standard Kit

The SigmaCheck 2 Eddy Current Conductivity Meter is designed to provide the user with fast and accurate conductivity measurements, while offering the best in reliability, usability, technology and cost effectiveness. The SigmaCheck 2 is easy to use, whether you are a shop inspector or an engineer.

It meets the requirements for conductivity measurements in the Aircraft manufacture and maintenance fields, where conductivity measurements are used to verify proper alloy/ temper or detect heat damaged components. It is also useful to determine the purity of precious metals or whether they are counterfeit.

Applications

Material verification / sorting
Heat treatment verification
Heat or fire damage investigation
Lightning damage investigation
Material aging assessment
Measuring phosphor content of Cu Alloys
Monitoring of deposition process for non-ferrous material on a non-ferrous substrate
Monitoring the condition of highly stressed parts
Forged / plated material verification
Non-conductive coating thickness measurement
Assessment of aging of alloys

Features

At a Glance:

High Resolution color display (2.8″ / 71mm, 320 pixels by 240 pixels)
Lockdown mode allows advanced users to lock down features and settings for basic operator mode
Accurate conductivity range (0.5% IACS to 110% IACS, 0.28-64 Ms/m)
Wide range of frequencies for testing thin materials (60kHz, 120kHz, 240kHz, 480kHz). Option of 960kHz
Non-conducive coating thickness. Measurement display up to 0.5mm
Lightweight (350 grams / 12oz.)
Ergonomic slim-line case design and easy to hold probe with adjustable finger grip
Two-year warranty on instrument (excludes batteries)

Show Less

Key Features:

Built-in Lithium Ion Battery
User programmable display
2GB of data storage on device with ability to store over 1 million data points
Removeable 32GB micro SD Card for data logger memory
Intelligent charger via Micro USB Port
Multiple languages available – English, French, German, Spanish.
Excellent resistance to “edge effect”
Rapid Display of Conductivity Results
Battery life up to 12 hrs.
Real-time PC control via USB or optional RS232 link

High Resolution Display:

The full color 2.8″ LCD Display screen is 320×240 pixels providing excellent resolution and displaying conductivity and lift-off results with up to three decimal places precision. The display features an adjustable LED backlight allowing the operator to set their required screen brightness.

Rapid Display of Conductivity Results:

The SigmaCheck 2 offers a choice of four frequencies (60, 120, 240, 480kHz) to allow the testing of a wide range of material thicknesses. The SigmaCheck 2 is noted for rapid display of conductivity results.

Excellent In-Field Performance & Data Reporting:

ETher NDE offers Field-Exchangeable probes with their configuration provided via micro SD Card or PC download via USB for the SigmaCheck 2. This removes the need for the instrument to be sent back for matching with the probe. USB PC Connectivity is built into the SigmaCheck 2 for remote control and data logging.
